Description

AJA Corvid 44 bi-directional 3G-SDI connection

AJA Corvid 44 allows AJA Developer Partner applications to access up to four simultaneous SDI input or output streams on a single PCIe card, making it perfect for a wide variety of medium-density applications.

Flexible Multi-Format I/O

AJA Corvid 44 Flexible Multi-Format I/O

Each 3G-SDI BNC connection on Corvid 44 BNC can be set programmatically as either an input or output and each can support a different video format, provided all formats use the same clock timing. Connections can also be linked together to support dual-link or 4K/UltraHD formats.

High Frame Rate support

AJA Corvid 44 High Frame

Corvid 44 BNC supports 4K (4096 x 2160) and UltraHD (3840 x 2160) High Frame Rate (HFR) workflows. Working at frame rates of 48p, 50p, and 60p ensures smooth motion for the most demanding 4K and UltraHD applications.

High frame rates are not limited to 4K and UltraHD with Corvid 44 BNC, multiple 720p and 1080p HD inputs and outputs are also supported at frame rates up to 50p and 60p, making Corvid 44 BNC extremely flexible for your current and future needs.

64-Channel Audio For Complete Flexibility

Corvid 88 allows the ingest or output of up to 64 discrete audio channels across multiple SDI connections.

LTC and Reference Input

Corvid 44 BNC provides one external, switchable LTC/Reference Input connection on the back of the card. A second LTC input is available on an internal header for providing additional reference to Corvid 44 BNC.

RS-422

A built-in RS-422 connection is available as an external connection on Corvid 44 BNC. RS-422 allows control of external devices for frame accurate ingest and layoffs.

Additional information

Weight	N/A
Choose Product Variants	CRV44-BNC-R0, CRV44-BNC-NF, CRV44-S-R0, CRV44-S-NC1, CRV44-S-NCF, CRV44-S-NF, CRV44-T-R0, CRV44-T-NC1, CRV44-T-NCF, CRV44-T-NF

Features

4K/UltraHD/2K/HD/SD up to 50/60p
4x bidirectional 3G-SDI connections with 16-channel embedded audio per connection, up to a total of 64-channel/32-channel support
RGB 4:4:4 12-bit and YCbCr 4:2:2 10-bit HFR workflows supported
2x independent Mixer/Keyer widgets.
4x independent 16-ch 48 kHz SDI embedded audio I/O engines
4K Closed Caption Support
VPID signaling for SDR/HDR Transfer Characteristics, Colorimetry and Luminance via SDI
PQ, HLG and Dolby Vision Support
HDR Metadata Capture and Auto Playback Detection
Reference/LTC Input on the card (Analog black burst or Tri-level)
Full height and half height models
RS-422 on internal header or bracket with full height model
LTC input on internal header
Includes support for the Apple M1 chip

Specifications

Video Formats	(4K) 4096 x 2160p 23.98, 24, 25, 29.97, 30, 47.95 A/B, 48 A/B, 50 A/B, 59.94 A/B, 60 A/B (UltraHD) 3840 x 2160p 23.98, 24, 25, 29.97, 30, 48 A/B, 50 A/B, 59.94 A/B, 60 A/B (2K) 2048 x 1080p 23.98, 24, 25, 29.97, 30, 47.95 A/B, 48 A/B, 50 A/B, 59.94 A/B, 60 A/B (2K) 2048 x 1080PsF 23.98, 24, 25, 29.97, 30, 47.95 A/B, 48 A/B, 50 A/B, 59.94 A/B, 60 A/B (HD) 1080p 23.98, 24, 25, 29.97, 30, 50 A/B, 59.94 A/B, 60 A/B (HD) 1080PsF 23.98, 24, 25, 29.97, 30 (HD) 1080i 50, 59.94, 60 (HD) 720p 50, 59.94, 60 (SD) 625i 50 (SD) 525i 59.94
Video Input Digital	3G-SDI, SMPTE 425 RGB 4:4:4 12-bit, YCbCr 4:2:2 10-bit 1.5G-SDI, SMPTE 292M Single Link HD-SDI YCbCr 4:2:2 10-bit Dual Link RGB 4:4:4 12-bit, Dual Link YCbCr 4:2:2 10-bit 270 Mbps SDI, SMPTE 259M-C YCbCr 4:2:2 10-bit, 8-bit
Video Output Digital	3G-SDI, SMPTE 425 RGB 4:4:4 12-bit, YCbCr 4:2:2 10-bit 1.5G-SDI, SMPTE 292M Single Link HD-SDI YCbCr 4:2:2 10-bit Dual Link RGB 4:4:4 12-bit, Dual Link YCbCr 4:2:2 10-bit 270 Mbps SDI, SMPTE 259M-C YCbCr 4:2:2 10-bit, 8-bit
HDR	SDI: VPID signaling for SDR/HDR Transfer Characteristics, Colorimetry, and Luminance
Audio Input Digital	16-Channel 24-bit SDI embedded, 48 kHz synchronous
Audio Output Digital	16-Channel 24-bit SDI embedded, 48 kHz synchronous
Reference	Analog Color Black or HD Tri-level sync
BNC	4x 3G-SDI Din 1.0/2.3
Electrical Interface	8-lane PCIe 2.0
Size (w x d x h)	0.88″ x 7.25″ x 4.88″ (22.36 × 184.15 × 123.96 mm)
Weight	0.4 lb (0.2 kg)
Power	17W typical, 19W maximum
Environment	Safe Operating Temperature: 0 to 40 C (32 to 104 F) Safe Storage Temperature (Power OFF): -40 to 70 C (-40 to 158 F) Operating Relative Humidity: 10-90% non-condensing Operating Altitude: <3,000 meters (<10,000 feet) Airflow across the board for fanless models 100LFM @25deg C or lower, computer chassis must have a vented opening to the exterior, immediately adjacent to the PCIe shield (heatsink side), to permit 100LFM across the heatsink
