Description

AJA Hi5-12G-R 12G-SDI to HDMI 2.0 Conversion with Fiber Receiver

Fiber SFP-equipped Hi5-12G models are available including the AJA Hi5-12G-R receiver, which can receive 4K signals over long distances from a Fiber connected source signal to an HDMI destination with pass-on of the source through SDI or Fiber to a secondary destination. The Video Source Auto Switch Over feature (SDI and Optical Inputs) in Hi5-12G-R provides automatic input changeover with configurable Switch Over Priority selection (Last Valid Input, Priority SDI, and Priority Optical).

HDR(High Dynamic Range)

Hi5-12G-R HDR

HDR, or High Dynamic Range, provides the ability to display a wider and richer range of colors, much brighter whites, and much deeper, darker blacks than standard signals allow. This gives your imagery a more ‘dynamic’ look and allows for natural true-to-life colors to be communicated to your audience.

AJA Hi5-12G provides this support for your 4K/UltraHD/HD HDR pipelines to HDMI-compatible displays by generating HDR metadata in accordance with HDMI v2.0b/CTA-861-G. Hi5-12G also provides support for Hybrid Log Gamma (HLG) HDR displays over HDMI.

4K and UltraHD

Hi5-12G-R 4K and UltraHD

Typical 4K signals use a resolution of 4096 x 2160 pixels while UltraHD signals measure 3840 x 2160. This difference can prevent some monitors from being used either in full 4K workflows or in UltraHD workflows. Hi5-12G can compensate for these resolution differences, allowing UltraHD monitors to be used in 4K productions and vice versa.

Hi5-12G also supports High Frame Rate (HFR) inputs. 4K/UltraHD signals at 50 or 60 fps can be fed into Hi5-12G and output at up to 60p for viewing with appropriate HDMI 2.0 capable displays.

12G-SDI Support

The 12G-SDI input on Hi5-12G allows extremely high-quality signal representation through to the HDMI output for use with large raster and deep color workflows where image quality is critical.

Audio Integration

Up to 16-channels of embedded SDI audio are supported on input and can be passed to 8-channel of embedded HDMI audio on the output with the ability to delay the audio from 0 to 7 frames for proper synchronization with the output video. Two channels of analog audio output allow direct external monitoring without the need to Disembed the audio separately.

USB and Mini-Config Support

AJA’s free Mini-Config software can be used with any USB-enabled AJA Mini-Converter and provides an easy-to-use graphical interface with detailed information about the current input and output formats. Control all the parameters of any supported AJA Mini-Converter as well as loading firmware updates from AJA that add new features and functionality.

Universal Power Supply

All AJA Mini-Converters ship with a universal power supply that includes international plug connections for use around the world.

Compact and Portable

AJA Mini-Converters are small enough to fit behind a monitor, in the back of a rack, or directly on a camera rig. A locking power connector can’t accidentally pull loose and an optional P-TAP power cable allows for battery power in remote locations.

AJA Mini-Matrix

Information on the complete line of AJA Mini-Converters is now available as a mobile app on iOS. The Mini-Converter product line is extensive and this app helps you find the right converter for any situation, wherever you are.

Additional information

Weight	1.5 kg

Features

12G-SDI to HDMI 2.0 Conversion with LC Fiber Receiver

Pristine image fidelity and HFR support up to 60p for 4K/UltraHD 12G-SDI to HDMI 2.0 conversion with a single cable
Supports 12-bit workflows
Generates HDR10 metadata in accordance with HDMI v2.0b/CTA-861-G and supports HLG over HDMI
Provides a monitoring connection from professional 4K devices using 12G-SDI over coaxial or Fiber LC outputs to new displays with HDMI 2.0 inputs, for cost-effective monitoring
12G-SDI single link input with a reclocked SDI loop out for simpler SDI confidence monitoring or pass-on for SDI pipelines
Ships with a Fiber LC single channel SFP receiver for extending 4K signals over long distances
Uses 5-16 VDC power (DWP-U-R1 universal power supply included)
USB port used with Mini-Config software application to configure the device via PC/Mac
Five-year warranty

Specifications

Video Formats	(4K) 4096 x 2160p (UltraHD) 3840 x 2160p (2K) 2048 x 1080p (HD) 1920 x 1080p (HD) 1920 x 1080i (HD) 1280 x 720p (SD) 720 x 576i (SD) 720 x 480i Note: Raster and Frame Rate Dependent, please see Hi5-12G Video Formats in Documents and Manual
Video Input Digital	1x 12G-SDI BNC, SMPTE-259/292/424/2081/2082 YCbCr 4:2:2/4:4:4 RGB 4:4:4, SMPTE or Full level 8, 10, 12-bit Two Sample Interleave (2SI) 4K/UltraHD source mapping 1x 12 Gb SDI (4K) 4096 x 2160p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 (UltraHD) 3840 x 2160p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 1x 6 Gb SDI (4K) 4096 x 2160p 23.98, 24, 25, 29.97, 30 (UltraHD) 3840 x 2160p 23.98, 24, 25, 29.97, 30 1x 3 Gb SDI (Level A or B-Dual Link) (2K) 2048 x 1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 (2K) 2048 x 1080PsF 23.98, 24, 25, 29.97, 30 (HD) 1920 x 1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 (HD) 1920 x 1080PsF 23.98, 24, 25, 29.97, 30 (HD) 1920 x 1080i 50, 59.94, 60 (HD) 1280 x 720p* 50, 59.94, 60 1x 1.5 Gb SDI (2K) 2048 x 1080p 23.98, 24, 25, 29.97, 30 (2K) 2048 x 1080PsF 23.98, 24, 25, 29.97, 30 (HD) 1920 x 1080p 23.98, 24, 25, 29.97, 30 (HD) 1920 x 1080PsF 23.98, 24, 25, 29.97, 30 (HD) 1920 x 1080i 50, 59.94, 60 (HD) 1280 x 720p 50, 59.94, 60 1x 270 Mb SDI (SD) 625i 50 (SD) 525i 59.94*1280 x 720p is Level A Only
Input Signal Selection	1x 12G-SDI BNC, SMPTE-259/292/424/2081/2082 1x 12G-SDI Fiber LC connector, SMPTE 297/259/292/424/2081/2082 Nominal Wavelength: Rx 1260 nm (min), 1620 nm (max) Optical Sensitivity: -10 dBm (min 12 Gbps), -14 dBm (min 3 Gbps) Overload Power: -2 dBm (min)
Video Output Digital	1x HDMI Type A connector, HDMI v2.0b HDR infoframe generation with pass-through or override for Colorimetry and Transfer Characteristic YCbCr 4:2:2/4:4:4/4:2:0 RGB 4:4:4, SMPTE, or Full level 8, 10, 12-bit (HFR 4K/UltraHD 4:4:4 limited to 8-bit) (4K) 4096 x 2160p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 (UltraHD) 3840 x 2160p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 (2K) 2048 x 1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 (HD) 1920 x 1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 (HD) 1920 x 1080i 50, 59.94, 60 (HD) 1280 x 720p 50, 59.94, 60 (SD) 720 x 576i 50 (SD) 720 x 480i 59.94 If a connected monitor doesn’t support HDMI protocol the unit automatically switches to DVI protocol (which does not pass audio)
Audio Pass-Through Formats	PCM Dolby Digital (AC-3) Dolby Digital Plus (E-AC-3), including Atmos Immersive Sound (JOC)
Audio Input Digital	SDI embedded audio, 24-bit (SD limited to 20-bit), 16-channel
Audio Output Digital	HDMI-embedded audio, 24-bit, 8-channel
Audio Output Analog	2x RCA style connector, 2-channel -10dBu (nominal)
User Interface	USB port used with supplied cable and Mini-Config software application to configure and view device status via Mac or Windows
Size (w x d x h)	4.6″ x 4.02″ x 0.9″ (116.84 x 102.11 x 22.86 mm)
Weight	0.5 lb (0.3 kg)
Power	5-16VDC regulated, 11 watts, power supply required included with purchase AC Adapter: 100-240VAC, 50/60 Hz, universal input
Environment	Safe Operating Temperature: 0 to 40 C (32 to 104 F) Safe Storage Temperature (Power OFF): -40 to 60 C (-40 to 140 F) Operating Relative Humidity: 10-90% non-condensing Operating Altitude: <3,000 meters (<10,000 feet).
